Consistency & Stability

All Ancor products are manufactured with meticulous attention to details such as retention and fracture resistance.

Screws are manufactured from the best quality steel and titanium alloys in terms of biocompatibility and corrosion resistance.

Each screw type is given the most appropriate thread depth to increase retention and retention time in the mouth.

Screws also have optimal main body thickness to prevent breakage during application.

Due to the special form given to the threads and entry ends, screws can be easily placed in all types of bones.

It can be applied to all hard tissues in the mouth without compromising durability.

Mini Screw

Mushroom Head Stainless Steel
  • Code Diameter & Length
  • MSM 1.4-6-SS 1.4 x 6 mm
  • MSM 1.4-8-SS 1.4 x 8 mm
  • MSM 1.4-10-SS 1.4 x 10 mm
  • MSM 1.6-6-SS 1.6 x 6 mm
  • MSM 1.6-8-SS 1.6 x 8 mm
  • MSM 1.6-10-SS 1.6 x 10 mm
  • MSM 1.6-12-SS 1.6 x 12 mm
  • MSM 1.8-8-SS 1.8 x 8 mm
  • MSM 1.8-10-SS 1.8 x 10 mm
  • MSM 1.8-12-SS 1.8 x 12 mm
  • MSM 1.8-14-SS 1.8 x 14 mm
  • MSM 2.0-8-SS 2.0 x 8 mm
  • MSM 2.0-10-SS 2.0 x 10 mm
  • MSM 2.0-12-SS 2.0 x 12 mm
  • MSM 2.0-14-SS 2.0 x 14 mm
  • MSM 2.0-16-SS 2.0 x 16 mm
  • MSM 2.2-14-SS 2.2 x 14 mm
  • MSM 2.2-16-SS 2.2 x 16 mm
Bracket Head Stainless Steel
  • Code Diameter & Length
  • MSB 1.4-6-SS 1.4 x 6 mm
  • MSB 1.4-8-SS 1.4. x 8 mm
  • MSB 1.4-10-SS  1.4 x 10 mm
  • MSB 1.6-6-SS 1.6 x 6 mm
  • MSB 1.6-8-SS 1.6 x 8 mm
  • MSB 1.6-10-SS 1.6 x 10 mm
  • MSB 1.6-12-SS 1.6 x 12 mm
  • MSB 1.8-8-SS 1.8 x 8 mm
  • MSB 1.8-10-SS 1.8 x 10 mm
  • MSB 1.8-12-SS 1.8 x 12 mm
  • MSB 1.8-14-SS 1.8 x 14 mm
  • MSB 2.0-8-SS 2.0 x 8 mm
  • MSB 2.0-10-SS 2.0 x 10 mm
  • MSB 2.0-12-SS 2.0 x 12 mm
  • MSB 2.0-14-SS 2.0 x 14 mm
  • MSB 2.0-16-SS 2.0 x 16 mm
  • MSB 2.2-14-SS 2.2 x 14 mm
  • MSB 2.2-16-SS 2.2 x 16 mm
Mushroom Head Titanium
  • Code Diameter & Length
  • MSM 1.4-6-Ti 1.4 x 6 mm
  • MSM 1.4-8-Ti 1.4 x 8 mm
  • MSM 1.6-6-Ti 1.6 x 6 mm
  • MSM 1.6-8-Ti 1.6 x 8 mm
  • MSM 1.6-10-Ti 1.6 x 10 mm
  • MSM 1.8-8-Ti 1.8 x 8 mm
  • MSM 1.8-10-Ti 1.8 x 10 mm
  • MSM 2.0-8-Ti 2.0 x 8 mm
  • MSM 2.0-10-Ti 2.0 x 10 mm
Bracket Head Titanium
  • Code Diameter & Length
  • MSB 1.4-6-Ti 1.4 x 6 mm
  • MSB 1.4-8-Ti 1.4. x 8 mm
  • MSB 1.6-6-Ti 1.6 x 6 mm
  • MSB 1.6-8-Ti 1.6 x 8 mm
  • MSB 1.6-10-Ti 1.6 x 10 mm
  • MSB 1.8-8-Ti 1.8 x 8 mm
  • MSB 1.8-10-Ti 1.8 x 10 mm
  • MSB 2.0-8-Ti 2.0 x 8 mm
  • MSB 2.0-10-Ti 2.0 x 10 mm

Products required for the application

The products required for each type of mini screw application are listed below. Screwdriver handle and screwdriver bit are absolutely necessary for manual application. However, if anguldruva is to be used, 20-25 and 30 mm long anguldruva tips are required. For this, either a physiodispenser or a Turret, also manufactured by Ancor, is required. At the same time, a set box can be added for both sterilization and storage of the products.
